FULLY ENCLOSABLE TENTS

4x4 (Full Tent) 5x5 (Full Tent)
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 75kg 115kg
Tube frame pressure 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Doors 4 4
Netted Windows 8 8
Storm covers over Doors/windows Yes Yes
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Cover and storm covers PVC coated Polyester fabric 400 gr/sqm PVC coated Polyester fabric 400 gr/sqm
Groundsheet PVC coated Polyester fabric 600 gr/sqm PVC coated Polyester fabric 600 gr/sqm
Netting over windows PVC coated Polyester netting PVC coated Polyester netting
Inflatable tubing (Inflatable boat fabric) PVC coated Polyester fabric 1000 grm/sqm PVC coated Polyester fabric 1000 grm/sqm

GAZEBO-STYLE TENTS

4x4 (Gazebo) 5x5 (Gazebo)
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 55kg 80kg
Tube frame pressure 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Groundsheet PVC fabric 600 gr/sqm PVC fabric 600 gr/sqm
Inflatable tubing(boat fabric) PVC fabric 1000 grm/sqm PVC fabric 1000 grm/sqm

CUSTOMISATIONS

ARK can provide custom branding and labelling
Additional securing points can be added.

4x4 5x5
Floor dimensions 4m x 4m 5m x 5m
Height 2.8m 3.5m
Weight 75kg 115kg
Tube frame 0.29 bar 0.29 bar
Inflation/deflation valves 22mm 1 1
Pressure safety valves Optional Optional
Doors 4 4
Netted Windows 8 8
Storm covers over Doors/windows Yes Yes
Packed dimension 1,3m x 0,6m x 0,6m 1,5m x 0,7m x 0,7m
Fabric
Cover and storm covers PVC coated Polyester fabric 400 gr/sqm PVC coated Polyester fabric 400 gr/sqm
Groundsheet PVC coated Polyester fabric 600 gr/sqm PVC coated Polyester fabric 600 gr/sqm
Netting over windows PVC coated Polyester netting PVC coated Polyester netting
Inflatable tubing(Inflatable boat fabric) PVC coated Polyester fabric 1000 grm/sqm PVC coated Polyester fabric 1000 grm/sqm

NILE KN. SERIES

SERIES

KN365
KN400
KN430

APPLICATIONS

Commercial white water adventure rafting | Equipped for up to grade 5 rivers

DESIGN PHILOSOPHY

When we created the NILE KN-Series, we wanted a fast and maneuverable raft that could handle low-volume bony waters but still go the whole hog on a grade 5 river. We made it super buoyant, and gave it a long nose and a well-kicked bow that radically reduces the waterline drag in quiet water, while giving it the effect of a longer boat in white water. The result: improved performance all round. All boats in the NILE KN- Series are fast, maneuverable inflatables that remain totally predictable at all times.

CUSTOMIZABLE

Whilst the NILE is considered one of the world's best all-round rafts, we acknowledge that all rivers and river operations are unique and that many require customization adapted for this. Our production and design techniques allow us almost limitless versatility. Fully digital cutting and CAD design processes make this a reality. Customisable features such as tube shapes with higher and lower kick and rocker, through to D-ring placement and foot straps. In short, any raft is possible. Your dream raft has arrived.

BRANDING

Even more exciting, you can brand your raft as much as your fantasy (and budget) desires. Just email us your logos and artwork or let us design it for you. ARK is highly experienced at branding boats with corporate identities and sponsorship promotions.

SPECIFICATIONS

STANDARD FEATURES

  • High performance 520-mm tubes
  • Full-wrap double skin
  • Rubber fender
  • Fixed I-Beam floors (retrofit system, for easy replacement)
  • Large volume Inflation valves
  • 7 air chambers (minimum)
  • Fixed or removable thwarts
  • Heavy Duty Stainless D-rings for full perimeter Grab line
  • 18mm Grab line
  • 6 conveniently placed carry handles for easy portage
  • Optional Xtra D-rings for the oar rig and gear tie downs

DIMENSIONS AND TECHNICAL SPECIFICATIONS

Series KN365 KN400 KN430
Packed Size and Weight 95 x 48 x 48cm (53kg) 90 x 55 x 50cm (61kg) 100 x 60 x 52cm (70kg)
Length 3.65m 4.0m 4.3m
Width 1.75M 1.96m 1.96m
Tube Diameter 520mm 520mm 520mm
Stern / Bow Kick 70cm / 70cm 76cm / 76cm 76cm / 76cm
Thwarts 2 2-3 2-4
Thwart Diameter 300mm 300mm 300mm
Air Chambers 5 + thwarts 5 + thwarts 5 + thwarts
Capacity 3-5 persons 4-7 persons 4-9 persons

COLOURS

Available in any combination of the colours listed below:

Tube Trim Thwart
Red Red Red
Yellow Yellow Yellow
Grey Grey Grey
Royal Blue Royal Blue Royal Blue
Orange Orange
Black Black

CUSTOMISATIONS

  • Asymmetric high kick bow, low kick stern or any other variation possible (Standard is Medium- Medium)
  • Branding - full colour logos or standard lettering/numbering - you supply logos and artwork or let us do it for you
  • Optional footcups
  • Additional thwarts
  • Thwart size
  • Thwart attachment: fixed, removable D-ring, or removable/adjustable slotted baton
  • Additional carry handles
  • Additional D-rings for tie downs and Oar rigs.
  • Portage bag
  • Material ARK can supply rafts in different fabric specifications for particular applications (e.g. Polyurethane, and Poly/PVC blends)
  • Colours other than those in the colour table above are possible dependent on availability

If this is the boat you're after contact us.
